| Processor |
Industrial-grade processor |
| Operating System |
Embedded LINUX |
| Channel |
16 |
| User Interface |
Web, Local GUI |
| Video Output |
1 HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 1 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 |
| Video Compression |
H.265, H.264, MJPEG |
| Encode Strategy |
Instastream |
| Decoding Capability |
AI disabled: 1-channel 12 MP@30 fps, 1-channel 8 MP@30 fps, 2-channel 5 MP@30 fps, 3-channel 4 MP@30 fps, 6-channel 1080p@30 fps AI enabled: 1-channel 8 MP@30 fps, 1-channel 5 MP@30 fps, 2-channel 4 MP@30 fps, 4-channel 1080p@30 fps |
| Video Resolution |
12 MP, 8 MP, 6 MP, 5 MP, 4 MP, 3 MP, 2MP, 960p, 1MP, D1 |
| Video Display Split |
Main screen: 1/4/8/9/16/25 Sub screen: 1/4/8/9/16 |
| SMD Plus by NVR |
4 channels |
| SMD Plus by Camera |
Perimeter protection, SMD Plus |
| Network Bandwidth |
AI disabled: 144 Mbps incoming, 144 Mbps recording and 72 Mbps outgoing AI enabled: 72 Mbps incoming, 72 Mbps recording and 36 Mbps outgoing |
| Smart Phone |
iPhone, iPad, Android Phone |
| Interface Ports |
2 (1 front USB 2.0 port, 1 rear USB 2.0 port) |
| Protocols |
HTTP, HTTPS, TCP/IP, IPv4/IPv6, RTSP, UDP, SNMP, NTP, DHCP, DNS, SMTP, UPnP, IP Filter, PPPoE, FTP, DDNS, Alarm Server, IP Search, Multicast, InstaOn cloud, Auto Registration, ONVIF 21.12(Profile T, Profile S, Profile G) |
| Browser |
Chrome, IE9 and later, Firefox, Edge |
| Ethernet |
1 (10/100/1000 Mbps Ethernet port, RJ-45) |
| Intelligent Alarm |
Perimeter protection, SMD Plus |
| Alarm Linkage |
Recording, snapshot, buzzer, log, preset, email, tour |
| Alarm Input |
NA (2 channels are optional) |
| Alarm Output |
NA (2 channels are optional, one of them is 1-channel 12 V 1 A output) |
| Audio Input |
1-channel RCA |
| Audio Output |
1-channel RCA |
| Audio Compression |
G.711a, G.711u, PCM, G726, AA |
| Hard Disk |
2 SATA ports. Each disk can contain up to 20 TB. this limit varies depending on the environment temperature |
| Multi-channel Playback |
Up to 16 channels |
| Record Mode |
General, motion detection, intelligent, alarm |
| Backup Method |
USB device and network |
| Power Supply |
12 VDC, 2 A |
| Power Consumption |
≤ 10 W (without HDD) |
| Operating Temperature |
Temperature -10 °C to +55 °C (14 °F to +131 °F) |
| Operating Humidity |
10%–93% (RH) |
| Storage Temperature |
-20 °C to +60 °C (–4 °F to +140 °F) |
| Dimensions |
375.0mm × 282.9mm × 53.0mm |
| Weight |
1490 g (without HDD) |
