| Image Sensor |
1/2.8” 4MP CMOS Image Sensor (0.9071 centimeters) |
| Resolution |
4MP |
| Video Compression |
H.265/ H.264 |
| Video Streaming |
Main stream: 2560 x 1440, Sub-stream：800 x 448 |
| FPS |
15fps |
| Lens |
4mm |
| Angle of view |
Horizontal:77.32°, Vertical:42.61° |
| Max. Aperture |
F2.0 |
| S/N Ratio |
38dB |
| Noise Reduction |
3D DNR |
| WDR |
DWDR |
| Min. Illumination |
Color: 0.1Lux, Black and white 0.01Lux |
| Electronic Shutter |
1/50s(1/60s)-1/100000s |
| Picture Adjustment |
Auto-adjust Contrast, Brightness, Saturation |
| Exposure Conditions |
Auto-adjust AWB, AGC, BLC |
| IR Distance |
IR Range of 30Mtr. |
| IR cut filter |
Dual IR-CUT Filter auto switch |
| IR Number |
4pcs IR LEDs |
| White Light Distance |
Warm Light Range of 20 Mtr. |
| White LED Number |
4pcs Spotlight LEDs |
| PIR Detection |
Up to 10 Mtr |
| Motion Detection |
Support |
| Motion Tracking |
Support |
| Pan/Tilt Angle |
Pan:266°, Tilt:90° |
| Alarm Notification Push |
Support |
| Two-way Talk |
Support |
| Human body Detection |
Support |
| Built-in Siren |
Support |
| Audio Compression |
AAC, G711A |
| Audio Input |
Built-in Mic |
| Echo Cancellation |
Support |
| Audio Output |
Built in speaker |
| 4G Frequency Band |
FDD-LTE:B1/B3/B5/B8, TDD-LTE:B34/B38/B39/B40/B41 |
| 4G Standard |
LTE-TDD / LTE FDD |
| Micro SD Card |
Micro SD Card, Max. 256 GB |
| smart phone |
Android, iOS |
| Application Environment |
Outdoor |
| Weatherproof Standard |
IP66 |
| Operating Temperature |
-20˚ C ~50˚ C |
| Solar Panel |
7W |
| Battery |
Built in 4 x 21700 type battery (Total 18000mAH) |
| Battery backup |
Upto 48h* |
| Operating Humidity |
<95%(no condensation) |
| Power Source |
Type-C, DC 5V-2A |
| Power Consumption |
≤8W |
| Casing |
Plastic |
| Weight |
1.718kg (without battery) |
| Dimensions |
132mm x 191mm x 170mm |
