| Processor |
Dual-core embedded processor |
| IP Camera Input |
8 channel |
| Operating System |
Embedded LINUX |
| Two-way Talk |
1 channel Input, 1 channel Output, RCA |
| User Interface |
GUI |
| Video Output |
1 HDMI, 1 VGA |
| Video Compression |
Instastream/H.265/Smart H.264+/H.264 |
| Video Resolution |
HDMI: 3840×2160, 1920×1080, 1280×1024, 1280×720 VGA: 1920×1080, 1280×1024, 1280×720 |
| Decoding Capacity |
8 channels@1080P(30fps) |
| Network Bandwidth |
200 Mbps for access, 200 Mbps for storage and 96 Mbps for forwarding |
| Recording Resolution |
8MP/ 6MP/ 5MP/ 4MP/ 3MP/ 1080P/ 1.3MP/ 720P etc. |
| Video Display Split |
1/4/8/9 |
| Perimeter Protection by Camera Performance |
8 channels |
| AI Search Perimeter Protection |
Search for pictures by channel, time and event type |
| SMD Plus by Camera |
8 channels |
| AI Search SMD |
Search by target classification (human, vehicle) |
| Motion Detection |
MD Zones: 396(22×18) |
| Video Loss |
supports |
| Camera Blank |
Supports |
| Alarm Input |
4 Channel |
| Alarm Output |
2 Channel |
| Audio Input |
1 channel, RCA connector |
| Audio Output |
1 channel, RCA connector |
| Hard Disk |
2 SATA III ports, up to 10TB Each |
| Smart Phone |
iPhone, iPad, Android Phone |
| Trigger Events |
Recording, PTZ, Tour, Video Push, Email, Snapshot, Buzzer & Screen tips |
| Recording Mode |
Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Tampering, Video Loss), Stop |
| Search Mode |
Time/Date, Alarm, MD & Exact search (accurate to second), Smart search |
| Disk Group |
Supports |
| General Alarm |
Motion detection; privacy masking; video loss; PIR alarm; IPC alarm |
| Anomaly Alarm |
Camera offline; storage error; full storage; IP conflict; MAC conflict; login lock; network security anomaly |
| Intelligent Alarm |
Perimeter protection; SMD; people counting; heat map |
| Alarm Linkage |
Record; snapshot; IPC external alarm output; buzzer; log; preset; email |
| Playback Function |
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
| Backup Mode |
USB Device/Network |
| Interface Ports |
2 USB Ports (1 USB2.0, 1 USB3.0) |
| Max User Account |
128 users |
| Record Interval |
1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
| Ethernet |
1 RJ-45 port (10/100M/1000Mbps) |
| Protocols |
HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, IGMP, ARP, SSL, ANR, RTP, QoS, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, SNMP, FTP, IP Search, ONVIF 2.4, SDK, CGI Conformant |
| Power Supply |
DC12V/4A |
| Power Consumption |
<6.9W (Without HDD) |
| Working Temp |
-10 ~+55°C / 10~90%RH / 86~106kpa |
| Dimension |
375mm x 281.5mm x 56mm |
| Weight |
1.6kg (without HDD) |
