Dahua 24-port Managed PoE Switch [ DH-PFS4226-24ET-240 ]

• Layer 2 Managed PoE Switch
• Supports PoE, PoE+, and Hi-PoE (use with PFT1300 PoE Extender)
• 240 W PoE Budget
• 250 m (820 Ō ) PoE Transmission
• PoE Management, PoE Seƫ ng/Event StaƟ sƟ cs/Green PoE
• Search and Upgrade via Confi guraƟ on Tool
• High Lightning ProtecƟ on Design
• Non-blocking Video Transmission

Technical Specifi caƟ on
Ethernet Ports
Two (2) 10/100/1000 Base-T (Combo Port)
Two (2) 1000 Base-X (Combo Port)
24 x 10/100 Base-T Ports (PoE Power Supply)
PoE Power Consumption
Ports 1 and 2: Hi-PoE (60 W), PoE+, PoE
Maximum per Port: ≤ 30 W
Total Power Consumption: ≤ 240 W
PoE Protocol PoE (IEEE802.3af), PoE+ (IEEE802.3at), Hi-PoE
Switching Capacity 8.8 Gbps
Packet Forwarding Rate 6.55 Mpps
Power Requirements 100 VAC to 240 VAC
Working Temperature -10° C to 55° C (14° F to 131° F)
Application Humidity 10% to 90%
Lightning Protection Common Mode: 4 KV
Differential Mode: 2 V
Dimensions (W x D x H) 440.0 mm x 300.0 mm x 44.0 mm
(17.32 in. x 11.81 in. x 1.73 in.)
Weight 3.51 kg (7.74 lb)
CerƟ fi caƟ ons
Safety EN 60950-1:2006+A11:2009+A1:2010+A12:2001+A2:2013
UL 60950-1 + CAN/CSA C22.2 No. 60950-1-07
Electromagnetic
Compatibility (EMC)
FCC CFR 47 Part 15 subpart B
EN 50130-4:2011+A1:2014, EN 55024:2010+A1:2015,
EN 55032:2015, EN 6100-3-2:2014, EN 61000-3-3:2013

Rev 001.002 © 2017 Dahua. All rights reserved. Design and specifi caƟ ons are subject to change without noƟ ce.
Service Specifi caƟ on
System
Username/Password: admin/admin
IP Address: 192.168.1.110/24
PoE Budget 240 W
MAC Table Size 4K
VLAN 802.1Q Standard VLAN
Spanning Tree STP, RTSP
Port Aggregation Static Link Aggregation, LACP Protocol
Port Mirroring Many-to-One Port Mirroring
DHCP DHCP-client Support
Long Distance Mode Power and Data Transmission Distance up to 250 m
(820.21 ft)
Flow Control
Half-duplex based on back pressure type control
Full Duplex based on PAUSE Frame
Security Features IP+MAC Binding, based on port
IEEE802.1x Port Authentication
System Maintenance One-key Recovery, Updated Packet Upload, System Log
QoS High and Low Priority, WRR, 802.1P, DSCP,
Supports priority according to protocol
Network Management Web (HTTP and HTTPS Protocols), SNMP V1/V2C/V3
PoE Management
PoE Setting (real-time port consumption)
PoE Event Statistics
Green PoE
