Dahua IP Video Intercom KIT [ DHI-KTP03 ]

Dahua IP Video Intercom KIT [ DHI-KTP03 ]

₹10,000.00
Digestive Health

Free shipping orders above ₹1249

Digestive Health

Quick payment, secure & fast

Premium And Safe Packaging

  • IP Villa Door Station
  • Megapixel image sensor
  • Supports IR illumination and night vision.
  • Two-way audio and voice call through app.
  • Can be managed through the management platform; supports voice call between App and the door station.
  • Card unlock, unlock on the indoor monitor, and remote unlock through the App.
  • Supports IP65 (Silicone sealant is needed.
  • For details, see the quick start guide.)
  • Supports 10000 cards.
  • Supports standard PoE power supply.
  • Controls two locks.
  • IP Indoor Monitor
  • 7″ TFT capacitive touch screen, 1024 × 600.
  • 6-channel alarm input and 1-channel alarm output.
  • Standard PoE.
  • Door station and IPC monitor.
  • H.265 and H.264 video decoding.
  • High performance & cost-effective.
Technical Specification
Model DHI-VTO2111D-P-S3
System
Main Processor Embedded Processor
Operating System Embedded Linux OS
Button Type Mechanical
Interoperability ONVIF; CGI
Network Protocol SIP; P2P; IPv4; DNS; RTSP; RTP; TCP; UDP
Basic
Camera 1/2.8″ 2 MP CMOS high definition, low illumination/DWDR/ color/IR
Field of View H: 107°; V: 60°; D: 122°
Noise Reduction 3D NR
Video Compression H.264; H.265
Video Resolution Main stream: 720p, WVGA, D1, CIF
Sub stream: 1080p, WVGA, D1, QVGA, CIF
Video Frame Rate PAL: 25 fps;
NTSC: 30 fps
Video Bit Rate 256 Kbps–8 Mbps
Light Compensation Auto IR
Day/Night Auto(ICR)/Color/B/W;Color/B/W
Audio Compression G.711a; G.711u; PCM
Audio Input 1
Audio Output Built-in speaker
Audio Mode Two-way audio
Audio Enhancement Echo suppression/digital noise reduction
Audio Bit Rate 16 KHz, 16 bit
Function
Communication Mode Full digital
Unlock Mode Card; app; indoor monitor
Card Type IC card
Leave Videos Yes (SD card inserted in VTH is needed)
Web Configuration Yes
Performance
Card Reading Distance 0 cm–4.5 cm (0″–1.77″)
Issue Card Locally Yes
Casing Material PC + Acrylic
Capacity
Card Capacity 10000
Port
RS-485 1
Power Output 1 port, 12 V and 200 mA
Exit Button 1
Door Status Detection 1
Lock Control 1 port, normally closed by default
Network Port 1 × 10/100 Mbps network port (8-core white
ribbon cable)
Alarm
Tamper Alarm Yes
General
Appearance Color Black
Power Supply 12 VDC, 1 A
Standard PoE
Power Adapter Optional
Installation Surface Mount
Certifications CE
Accessory Included: Alarm power ribbon cable, rain cover, brackets
Product Dimensions 135.1 mm × 70.6 mm × 34.6 mm (5.32″ × 2.78″ × 1.36″)
Protection IP65 (silicone sealant is needed, see the quick start guide.) IK04 (for common use)
Operating Temperature –30 °C to +60 °C (–22 °F to +140 °F)
Operating Humidity 10%–90% (RH), non-condensing
Operating Altitude Beneath 3000 m (9842.52 ft)
Operating Environment Outdoor
Power Consumption ≤ 1 W (standby), ≤ 5 W (working)
Gross Weight 326 g (0.72 lb)
Anti-corrosion Level Basic Protection
Model DHI-VTH2621G-P
System
Main Processor Embedded Processor
Operating System Embedded LINUX OS
Basic
Screen Type Capacitive Touchscreen
Display Screen 7″ TFT
Screen Resolution 1024 (H) × 600 (V)
Audio Compression G.711a; G.711u; PCM
Audio Input 1
Audio Output Built-in speaker
Audio Mode Two-way voice talk
Audio Enhancement Echo suppression
Audio Bit Rate 16 KHz; 16 bit
Function
Communication Mode Full digital
Information Release Receive and view text information released by the management center
Leave Videos Yes (an SD card inserted in VTH is needed)
DND Mode Do not disturb period can be set;Do not disturb mode can be set
Number of Extensions Villa: 9:
Apartment: 4
Storage Micro SD Card, Max 64 GB (reserved for software)
Port
Alarm Input 6
Alarm Output 1
Network Port 1 × 10/100 Mbps Ethernet port
Performance
Casing Material PC + ABS
General
Appearance Color Black
Power Supply 12 VDC, 1 A
Standard PoE
Installation Surface Mount
Accessory Bracket (included)
Alarm ribbon cable (included)
Product Dimensions 189.6 mm × 134.6 mm × 26.0 mm

(7.46″ × 5.30″ × 1.02″)
Operating Temperature –10°C to +55°C (+14°F to +131°F)
Operating Humidity 10%–95% (RH), non-condensing
Power Consumption Standby ≤ 2 W; working ≤ 6 W
Gross Weight 575 g (1.27 lb)
Storage Temperature Basic Protection
Model DH-PFS3006-4ET-36
System
Main Processor Embedded Processor
Port
Network Port 4 × PoE ports with 10/100 Mbps Base-TX
2 uplink ports with 10/100 Mbps Base-TX
General
Appearance Color Black
Certifications CE; FCC
Product Dimensions 194.0 mm × 108.1 mm × 35.0 mm (7.64″ × 4.26″ × 1.38″)
Gross Weight 0.56 kg (1.23 lb)
Anti-corrosion Level Basic Protection
